Kia Optima DL3: General Information / Basic Service Symbols
General information
| Basic Service Symbols |
There are five primary symbols used to complement illustrations. These symbols indicate the part to apply such materials during service.
|
Symbol |
Meaning |
|
|
Do not reuse the part. Replace a new one. |
|
|
Apply engine oil or transmission oil to the part. |
|
|
Apply automatic transmission fluid (ATF) to the part. |
|
|
Apply grease to the part. |
|
|
Apply sealant to the part. |
General information Identification Number Locations Protection of the Vehicle Always be sure to cover fenders, seats, and floor areas before servicing.
General information Identification Numbers Identification Number Description Vehicle Identification Number 1. World Manufacturer Identifier (WMI) - KNA : Passenger vehicle, MPV(Multipurpose Passenger Vehicle)/SUV(Sports Utility Vehicle)/RV(Recreational Vehicle) - KNC : Commercial vehicle (Van) - KND: MPV/SUV/RV (For U.
